| Panel Brand | RISINGSTAR | Panel Model | RS220WPM-NE10 |
| Panel Size | 22.0" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1680(RGB)×1050, WSXGA+, 90PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 473.76(W)×296.1(H) mm | Bezel Opening | 477.7(W)×300.1(H) mm |
| Outline Size | 493.7(W)×320.1(H) ×10.7(D) mm | Surface | Antiglare (Haze 25%), Hard coating(3H) |
| Brightness | 1000nit or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive |
| Display Colors | 16.7M 72% NTSC | Response Time | 1.5/3.5 (Typ.)(Tr/Td) |
| Frequency | 60Hz | Lamp Type | 3 strings WLED , 40K hours , Without Driver |
| Weight | 1.83Kgs (Typ.) | Input Voltage | 5.0V (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C | ||
RS220WPM-NE10 is a 22 inch svutugadzike inoverengwa LCD kuratidza iyo inotsigira lvds interface. Inogona kunge iri kushanda pakupisa kubva -20 ℃ ~ ℃ uye yekuchengetedza kupisa kubva -30 ~ ~ 80 ℃. RS220WPM-NE10 ndeye 1000 nits yakakwira kupenya Tft LCD Module. Izvo zvakakodzera midziyo yemaindasitiri, zvishandiso zvemaoko, zvigadzirwa zvekurapa, zvekunze uye zvakarongeka nharaunda.
Zvimiro
1. Kupenya kwakanyanya, kusiyanisa kwakanyanya, nguva yekukurumidza kupindura, remuviri-ruvara rutsigiro rwekona;
2. National Standard Professional Production Line, mamirioni enharare-dzemahara nharaunda, iyo skrini yemuviri uye yakarongedzwa screen yakakodzera;
3. Chitupa, FCC, CE, CCC, UL, Rohs;
4. Professional LED Backlight tekinoroji.
5. Sturdy chimiro, anti-ekunze kukanganisa, metal chassis.
1. Professional Outdoor Yakakura Kupenya LCD Panel Mugadziri
2. Professional yakakwira-kupenya LCD skrini, inogona kutsungirira 110 kupisa kwakanyanya
3. Samsung, LG, BEO, Auo, Innoxux Dare Makambani
4. Ikupa iwe neunyanzvi hwekunze technical tekinoroji uye nhungamiro
Q: Ndingatenga sampuli yeodha yangu here?
A: Ehe, ndapota inzwa wakasununguka kutibata nesu.
Q: Tingaitei kuti tivimbise hunhu?
A: Nguva dzose yekuedza kuongororwa kusati kwatumirwa;
Q: Ndezvipi zvibatsire zvedu?
A: Yakaderera mutengo mhando zvigadzirwa, ruzivo rwekutsvaga nguva.
Q: Iyo waranti yakadii?
A: Isu tinopa imwe gore waranti kubva pazuva rekutakura.
Q: Uri kutengesa kambani kana mugadziri?
A: Isu tiremedu.
