Min. Raira:1 Piece/Pieces
Mutengo: Risinglcd
Kubudirira: 150KK
Nzvimbo Yokutanga: Shen Zhen
Certificate: CE/ROSH/UL/ISO9001
| Panel Brand | BOE | Panel Model | MT220WPM-N10 |
| Panel Size | 22.0" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1680(RGB)×1050, WSXGA+, 90PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 473.76(W)×296.1(H) mm | Bezel Opening | 477.7(W)×300.1(H) mm |
| Outline Size | 493.7(W)×320.1(H) ×10.7(D) mm | Surface | Antiglare (Haze 25%), Hard coating(3H) |
| Brightness | 1000nit or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive |
| Display Colors | 16.7M 72% NTSC | Response Time | 1.5/3.5 (Typ.)(Tr/Td) |
| Frequency | 60Hz | Lamp Type | 3 strings WLED , 40K hours , Without Driver |
| Weight | 1.83Kgs (Typ.) | Touch Screen | Without |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
| Input Voltage | 5.0V (Typ.) | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C | ||
Ultra-yakaonda LCD PANEL, kupenya kunosvika 1000nit, iyo pikicha ichiri kujekesa zuva rakananga, rondedzero yakatarisana nepahwindo, zuva iri rinogona kugadzirwa LCD rinogona kugadzirwa kupenya: 600-1000nit.
21.5 inch dijitari show lcd skrini ine yakakwira kupenya yakatsvaga backlight module
1, Backlight module chimiro : Zvese aluminium chimiro, mwenje uye mutete, kutaridzika kwakanaka, kutaridzika kwakanaka, zvinobudirira kupisa.
2
3
4, chinyorwa Chinyorwa : Aluminium chimiro + chakatungamirwa kumashure, gadzirisa iyo inotungamirwa kumashure pane aluminium
21.5 Inch Light LCD Module Sunlight inoverengwa LCD Panel
Ultra Slim 21.5 Inch LCD Module Unganidza waya uye batanidza 3M yekunoratidza firimu yekuita kuti mwenje udzokere kuyaradzo Isa iyo 10,000-kirasi yakachena kamuri uye tarisa iyo mwenje wechiedza kuti uve nechokwadi chekuti iyo inotungamirwa kumashure inoshanda kazhinji.
Ultra slim 21.5 inch LCD module ine nzvimbo yekuisa optal flims
Slim yakakwira Brickness LCD module nzvimbo dzinoisa Optical Flims: Disfusion Plate Firimu, firimu remafirimu, etc kuvandudza kupenya uye kufanana kweshure.
Slim High Hright
Iyi slim 21.5 inch LCD module yaungana LG / Samsung / Auo / Boe Opt Opt Open Cell (yakajairwa giredhi giredhi rakakwira tni110 ℃)
Ultra slim 21.5 inch Lcd module ne t-con bhodhi
21.5 Inch Light LCD Module Inosangana T-Bhodhi Bhodhi, Liot Divitya Mabhandeji, Nguva Dc12v Power Supply.
21.5 inch yakakwira hright module nekujeka kwebvunzo
Uku kupenya kwakakwirira kwazvo 21.5 Inch LCD module, yapfuura kupenya bvunzo, ruvara tembiricha kupenya kwebvunzo, Topcon bm-7 color kupenya kupenya tester.
