Min. Raira:1 Piece/Pieces
Muenzaniso Nha.: LQ150X1LW96
Iyo LQ150X1LW96 RATIDZA RUDZIDZO IS 1024 (RGB)】 768 (XGA) Iyo Inoratidza Area Saizi yeLQ150X1LW96 ndeye 304.128 × 228.096 (w Aizi iri kuenzana 307.3 (W Hekishi h) mm. Matte apedza, zvakaoma kuunganidza (3H), ur uremu 950g (max.)
Iyo yekumberi inogamuchira iyo Edge-Type mwenje sosi, tembiricha yayo yekushandisa is -20 ° C, uye yekuchengetedza yayo yekudziya ndeye -25 ° C, iyo yakakodzera maindasitiri uye yekurapa ekufungidzira.
| brand | Sharp | Model name | LQ150X1LW96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 1500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1(H×V×D)mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | work environment | Storage temperature: -25 to 70 °C Operation Temperature: -20 to 70 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins | ||
| supply voltage | 3.3V (Typ.) |
Q: Iwe uri mugadziri (fekitori)?
A: Ehe, isu tiri. Zvakare oem / odm service inowanikwa pano.westm yekugovana mazano ako nesu. Iyo inonakidza kupa mhinduro dzakanakisa kwauri.
Q: Ndingatenga sampuli yeodha yangu here?
A: Ehe, ndapota inzwa wakasununguka kutibata nesu.
