Muenzaniso Nha.: LA123WF4-SR03
Iyo yekushandisa tembiricha yeLa123Wf4-sr03 is -40 ° CL, uye tembiricha yekuchengetedza ndeye -40 ° C. Iyo yekuratidzira resolution yeLa123WF4-SR03 is 1920 (RGB)
Iyo Inoratidza Area Saizi yeLa123Wf4-sr03 is 292.032 × 109.012 (W Kukura kwe19.03 D) mm, iko kurapwa kwemusoro kwakaoma kuwirirana.
Kutungamirwa uye kugadziriswa kusangana nezvakawanda zvemhoteredzo zvinodiwa.
Kukwira-nyeredzi General-chinangwa kuratidza mapaneru anoratidzira Ultra-yakakwirira resolution, yekuona kunze kwekuonekwa, uye yechigadzirwa chigadzirwa. Zvigadzirwa zvechigadzirwa zvinovhara otomatiki michina Marine anoratidza kumirira. Isu tinopa zvakare yakagadzirwa dhizaini uye yakabatanidzwa yekubata mhinduro kubatsira vatengi kukudziridza makwikwi emamiriro ekunze.
| brand | LG Display (LG Display) | Model name | LA123WF4-SR03 |
| size | 12.3 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution | 1920(RGB)×720 167PPI | Pixel configuration | RGB vertical bar |
| Display size | 292.032×109.512(H×V)mm | Surface treatment | Hard coating |
| Brightness(cd/m²) | 600 cd/m² (Min.) or customized | contrast | 800:1 (Min.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Appearance of size | 310×128×10.75mm(H×V×D) |
| Signal system | RSDS (2 Channel) , 110 pins , FPC | ||
| Maximum rated | Storage temperature: -40 ~ 95 °C Working temperature: -40 ~ 85 °C Vibration resistance: 3.0g (29.4m /s²) |
