Muenzaniso Nha.: LA123WF1-SR03
Iyo LA12WF1-SR03 RESTALUT REMAHARA ndeye 1920 (rGB) Saizi yenzvimbo yekuratidzira yeLa123Wf1-sr03 is 292.032 × 109.512 (Worth are Height)
[Iyo indasitiri inonyanya kuzara industrial panel chigadzirwa mutsara]
Kukwira nyeredzi kunopa mutsara wakazara wechigadzirwa kubva 10.1 "kusvika zana nharaunda.
| brand | LG Display (LG Display) | Model name | LA123WF1-SR03 |
| size | 12.3 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution | 1920(RGB)×720 167PPI | Pixel configuration | RGB vertical bar |
| Display size | 292.032×109.512(H×V)mm | Surface treatment | Fog surface, Hard coating (3H) |
| Brightness(cd/m²) | 600 cd/m² (Min.) or customized | contrast | 800:1 (Min.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Appearance of size | 310×128×16.2mm(H×V×D) |
| Signal system | RSDS (2 Channel) , 110 pins , FPC |
|
|
| Maximum rated | Storage temperature: -40 ~ 95 °C Working temperature: -40 ~ 85 °C Vibration resistance: 3.0g (29.4m /s²) |
|
|
Mota dzinopisa: , 1000nits Square LCD Show , LCD Panel, LCD Module, Yakanyanya Kupenya Kuzivisa.
LG Ratidza 12,3 "LA12WF4-SR03 LCD Dispiay
15.6 "Panel Lp156wfc-Spu2 500nits moudle
