Min. Raira:1 Piece/Pieces
Muenzaniso Nha.: EV101WXM-N81
Ev101WXM-N81 ndeye 10.1-inch LCD module uchishandisa a-si tft-lcd tekinoroji. Yakashongedzerwa nemhepo yakasviba, inosanganisira LED Driver Backlight Drive, hapana kubata. Display resolution is 1280 (RGB)】 800 (Wxga), Matanho Retio ndeye 16:10 (UPreh: Height), uye pixels yakarongedzwa muRGB vertical mitsetse. Yayo Ratidziro Area Saizi ndeye 216.96 × 135.6 (Worth】, saizi ×, (Type.). Panyaya yekudzosera kumashure, ichi chigadzirwa chinoshandisa yakashongedzwa side yekupinda kwechiedza sosi nehupenyu hwemaawa 50k, kusanganisira mutyairi akatungamira. Ev101WXM-N81 inoshandisa LVDS (1 CH, 8-BIT) Signal Interface, huwandu hwemakumi maviri, inoshandisa terminal yekubatanidza, drive screen voltage ndeye 3.3V (typ (type. Yayo yakajairwa vertial rezerber rate fv ndeye 60hz. Inoshanda pa -20 ° c kusvika 70 ° ° C uye zvitoro pa -30 ° C kusvika 80 ° C. Kubva pane chena yayo yakatsauka kumashure, hupenyu hunopfuura maawa makumi mashanu.
Rwendo rwakatangira kubva kuShenzhen, China, isu tiri mugadziri wehunyanzvi hwekupedzisira HCD, kusanganisira SEME-Outdoor Lcd Screen, Ultrathin Kukwirisa LCD, Kunze Kununurwa Simbisa LCD, Maindasitiri Simbisa Tft-LCD, Litrarrent LCD uye Ratidza Frame, kaviri-gcd LCD, yakakwirira-yakagadzirirwa LCD uye imwe yakakwirira-yekupedzisira LCD PAND. Muchidimbu, kusimuka kune anopfuura makore mashanu ekupenya kwekamhepo backlight modulology,
| brand | BOE | Model name | EV101WXM-N81 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1280(RGB)×800, WXGA, 149PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.96×135.6(H×V)mm | Surface treatment | / |
| Visual size | 233.2×152.9×10.4(H×V×D) mm | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 233.2×152.9×10.4(H×V×D)mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Iyo yakafanana saizi modhi uye paramita ndeyekutevera
| brand | BOE | Model name | EV101WUM-N20 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1200, WUXGA, 224PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.806×135.504mm(H×V) | Surface treatment | / |
| Visual size | / | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 229.45×149.22(H×V)mm |
| Viewing Angle | 80/80/80/80(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 45 pins | ||
| work environment | Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C |
| brand | BOE | Model name | AT101WSM-N11-58P0 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×600, WSVGA, 117PPI | Pixel configuration | RGB vertical bar |
| Display Area | 222.72×125.28mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 226×128.6(H×V)mm | Contrast Ratio | 500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 235×144.9×5.44mm(H×V×D) |
| Viewing Angle | 80/80/60/70(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) , 60 pins , FPC | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
| brand | BOE | Model name | EV101WXM-N82 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1280(RGB)×800 [WXGA] 149PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.96 × 135.6 mm (H×V) | Surface treatment | / |
| Visual size | / | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 228.6 ×149.2×6 mm (H×V×D) |
| Viewing Angle | 85/85/85/85(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 40 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
